GE 193X725AAG01發電機卡 PDF資料
1.產 品 資 料 介 紹：
中文資料：
一、產品簡介
GE 193X725AAG01 發電機卡是 GE（通用電氣）193X 系列中的一款重要模塊，專門用于發電機控制系統。該模塊用于采集發電機的工作狀態和性能參數，并將其轉換為系統所需的控制信號。它通常用于電廠、風電、船舶以及其他需要發電機監控和控制的應用環境中。
二、核心功能
發電機參數采集：實時采集發電機的工作參數，如輸出電壓、電流、頻率、轉速等。
狀態監測：監測發電機的狀態，包括負載、電流波動、溫度等，確保發電機的安全運行。
信號處理與轉換：將采集到的模擬信號轉換為數字信號，或將數字信號轉換為可操作的控制信號。
保護功能：具備短路保護、過載保護、過壓保護等功能，防止發電機出現異常時損壞。
通信功能：支持與控制系統的其他模塊進行通信，提供實時反饋，確保發電機的協調運行。
數據記錄與診斷：可記錄關鍵操作數據，支持故障診斷、報警和維護指示，幫助工作人員及時發現潛在問題。
三、技術參數（典型值）
輸入電壓范圍：AC 220V 或 DC 24V（根據應用要求配置）
輸入信號類型：模擬信號（電壓、電流、頻率等），數字信號（開關量輸入）
輸出信號類型：標準化模擬信號（如 0-10V、4-20mA）、數字信號輸出
工作頻率：50Hz/60Hz（自動適應）
精度：模擬信號精度 ±0.1%，數字信號誤差 ≤ 0.5%
過載保護：支持短路保護、過電流保護、過壓保護
工作溫度范圍：-10°C ～ +60°C
尺寸：符合 193X 系列標準插卡式結構（大約 25 × 15 cm）
四、應用領域
發電廠：用于發電機的監控和控制，確保發電機系統的安全與穩定運行。
風力發電：對風電機組的發電機進行監控和保護，確保發電效率和設備安全。
船舶控制系統：用于船舶發電機的運行監控，優化電力系統的管理。
工業自動化：在工業生產中為各類發電機提供實時監測和控制。
軍事與應急備用電源：在應急發電機系統中，確保電力供應的可靠性和持續性。
英文資料：
Brief introduction
The GE 193X725AAG01 generator card is an important module in the GE 193X series, specifically designed for generator control systems. This module is used to collect the working status and performance parameters of the generator, and convert them into the control signals required by the system. It is commonly used in power plants, wind power, ships, and other application environments that require generator monitoring and control.
2、 Core functions
Generator parameter collection: Real time collection of working parameters of the generator, such as output voltage, current, frequency, speed, etc.
Status monitoring: Monitor the status of the generator, including load, current fluctuations, temperature, etc., to ensure the safe operation of the generator.
Signal processing and conversion: Convert the collected analog signals into digital signals, or convert digital signals into operable control signals.
Protection function: It has short-circuit protection, overload protection, overvoltage protection and other functions to prevent damage to the generator in case of abnormalities.
Communication function: Supports communication with other modules of the control system, provides real-time feedback, and ensures the coordinated operation of the generator.
Data recording and diagnosis: It can record key operational data, support fault diagnosis, alarm and maintenance instructions, and help staff discover potential problems in a timely manner.
3、 Technical parameters (typical values)
Input voltage range: AC 220V or DC 24V (configured according to application requirements)
Input signal type: analog signal (voltage, current, frequency, etc.), digital signal (switch input)
Output signal type: standardized analog signal (such as 0-10V, 4-20mA), digital signal output
Operating frequency: 50Hz/60Hz (automatic adaptation)
Accuracy: Analog signal accuracy ± 0.1%, digital signal error ≤ 0.5%
Overload protection: supports short circuit protection, overcurrent protection, and overvoltage protection
Working temperature range: -10 ° C to+60 ° C
Size: Compliant with the 193X series standard plug-in card structure (approximately 25 × 15 cm)
4、 Application Fields
Power plant: used for monitoring and controlling generators to ensure the safe and stable operation of the generator system.
Wind power generation: Monitor and protect the generators of wind turbines to ensure power generation efficiency and equipment safety.
Ship control system: used for monitoring the operation of ship generators and optimizing the management of power systems.
Industrial automation: providing real-time monitoring and control for various generators in industrial production.
Military and emergency backup power supply: Ensure the reliability and continuity of power supply in emergency generator systems.
