ABB 1TGE120021R0010 控制單元 PDF資料
1.產 品 資 料 介 紹：
中文資料：
一、產品概述
ABB 1TGE120021R0010 是 ABB 公司生產的一款工業自動化控制單元，屬于 ABB 低壓自動化產品線，廣泛應用于配電控制、自動化系統集成及工業控制領域。該控制單元負責執行控制邏輯，實現自動監控和設備管理，保障系統的高效、穩定運行。
二、主要技術參數
| 參數項 | 說明 |
|---|---|
| 產品型號 | 1TGE120021R0010 |
| 類型 | 控制單元（控制模塊/控制器） |
| 應用領域 | 低壓配電自動化、工業自動化控制 |
| 輸入電壓 | 通常 24 V DC 或 230 V AC，具體型號需確認 |
| 控制方式 | 可編程邏輯控制，支持數字量與模擬量控制 |
| 通訊接口 | 可能包含 Profibus、Modbus、Ethernet 等工業通信協議接口 |
| 安裝方式 | DIN 導軌或面板安裝 |
| 環境適應性 | 工業級設計，耐高溫、防塵、防震 |
| 工作溫度 | -20°C 至 +60°C（典型） |
| 狀態指示 | 多功能 LED 指示，實時顯示運行狀態和故障狀態 |
| 兼容系統 | 兼容 ABB 低壓配電及自動化系統 |
三、功能特點
高可靠性控制：適合工業環境使用，確保自動化系統穩定運行。
多協議支持：支持多種工業通訊協議，方便與其他設備互聯。
靈活編程：支持用戶自定義邏輯和控制策略，滿足多樣化需求。
模塊化設計：方便系統集成和維護，支持快速更換。
狀態監測：提供豐富的診斷和報警功能，提升維護效率。
節能環保：低功耗設計，符合工業節能標準。
英文資料：
1、 Product Overview
ABB 1TGE120021R0010 is an industrial automation control unit produced by ABB. It belongs to ABB's low-voltage automation product line and is widely used in the fields of distribution control, automation system integration, and industrial control. This control unit is responsible for executing control logic, achieving automatic monitoring and equipment management, and ensuring the efficient and stable operation of the system.
2、 Main technical parameters
Parameter item description
Product model 1TGE120021R0010
Type control unit (control module/controller)
Application areas: Low voltage distribution automation, industrial automation control
The input voltage is usually 24 V DC or 230 V AC, and the specific model needs to be confirmed
Control method programmable logic control, supporting digital and analog control
The communication interface may include industrial communication protocol interfaces such as Profibus, Modbus, Ethernet, etc
Installation method: DIN rail or panel installation
Industrial grade design with environmental adaptability, high temperature resistance, dust resistance, and shock resistance
Working temperature -20 ° C to+60 ° C (typical)
Multi functional LED status indicator, real-time display of operating and fault status
Compatible with ABB low-voltage distribution and automation systems
3、 Functional Features
High reliability control: suitable for industrial environments to ensure stable operation of automation systems.
Multi protocol support: Supports multiple industrial communication protocols for easy interconnection with other devices.
Flexible programming: supports user-defined logic and control strategies to meet diverse needs.
Modular design: facilitates system integration and maintenance, supports quick replacement.
Status monitoring: Provides rich diagnostic and alarm functions to improve maintenance efficiency.
Energy saving and environmental protection: Low power design, in line with industrial energy-saving standards.
2.產 品 展 示
