產品名稱：ABB 1MRK000508-BDr03 控制板
產品類型：控制板 / 控制模塊（Control Board）
制造商：ABB
典型應用系統：繼電保護與控制裝置（如：REF、RET、REL 系列）
一、主要功能
信號處理與邏輯控制
用于處理采樣信號（如電壓、電流）并執行邏輯控制任務，如跳閘、閉鎖、告警等。
控制指令執行
接收來自上位機或保護程序的命令，并對斷路器、開關或其他執行器發出控制指令。
通信與數據交換
與系統主控模塊、通信接口或遠動裝置進行數據交互。
系統狀態監控與反饋
實時采集設備運行狀態并向主系統反饋運行參數或故障信號。
二、應用領域
數字變電站自動化系統（SAS）
作為繼電保護裝置的核心控制單元之一，用于監測和執行保護邏輯。
保護與控制裝置（IED）內部模塊
安裝于 ABB 的如 REL670、RET670、REF615 等設備內部，作為主控邏輯處理單元。
輸電/配電系統保護應用
用于110kV、220kV等高壓輸電系統的保護與控制系統中。
過程控制與開關命令管理
參與過程控制閉環中的決策執行，例如跳閘邏輯判斷、故障處理等。
三、技術特點（常規）
支持多輸入多輸出邏輯控制
工業級電路板，抗干擾能力強，適合高壓環境使用
模塊化結構，便于設備組裝與維護更換
支持與ABB主系統通信協議（如IEC 61850）
穩定性高，適合長時間連續運行
英文資料：
Product Name: ABB 1MRK000508-BDr03 Control Board
Product Type: Control Board/Control Module
Manufacturer: ABB
Typical application systems: Relay protection and control devices (such as REF, RET, REL series)
1、 Main functions
Signal Processing and Logic Control
Used to process sampling signals (such as voltage, current) and perform logic control tasks, such as tripping, locking, alarm, etc.
Control instruction execution
Receive commands from the upper computer or protection program, and issue control instructions to circuit breakers, switches, or other actuators.
Communication and Data Exchange
Interact data with the system's main control module, communication interface, or remote control device.
System status monitoring and feedback
Real time collection of device operating status and feedback of operating parameters or fault signals to the main system.
2、 Application Fields
Digital Substation Automation System (SAS)
As one of the core control units of relay protection devices, it is used to monitor and execute protection logic.
Internal modules of protection and control devices (IEDs)
Installed inside ABB devices such as REL670, RET670, REF615, etc., as the main control logic processing unit.
Application of transmission/distribution system protection
Used in the protection and control systems of high-voltage transmission systems such as 110kV and 220kV.
Process control and switch command management
Participate in decision execution in the process control loop, such as trip logic judgment, fault handling, etc.
3、 Technical characteristics (conventional)
Support multi input multi output logic control
Industrial grade circuit board with strong anti-interference ability, suitable for use in high-voltage environments
Modular structure, easy to assemble, maintain and replace equipment
Support communication protocols with ABB main systems (such as IEC 61850)
High stability, suitable for long-term continuous operation
