ABB 1MRK002305-AAr01時間同步模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
產品名稱：1MRK002305-AAr01 時間同步模塊
產品類型：時間同步單元 / 模塊
制造商：ABB
適用系統：用于 ABB 電力自動化系統，特別是繼電保護裝置和數字化變電站系統（如 670 系列 IED）
一、核心功能
時間同步管理
接收外部標準時間信號（如 IRIG-B、SNTP/NTP、1PPS 等），為保護裝置、測控單元提供統一時間基準。
高精度時間分發
向多個系統模塊（如控制板、通信板、錄波單元）提供同步時鐘脈沖，確保事件順序（SOE）準確。
與上層時鐘源協同運行
可通過 GPS 接收機、主時鐘裝置、SCADA 系統同步整站時鐘。
支持多種時間協議輸入
通常支持 IRIG-B（串行/并行）、SNTP/NTP（以太網）、1PPS（脈沖）等方式。
二、應用領域
繼電保護裝置（如 REL670、REF615、RET670）
提供內部邏輯運算與事件記錄的時間基準，保證操作時序的準確性。
數字變電站自動化系統（IEC 61850 環境）
支持站級與間隔級設備時間統一，同步 MMS 報文、GOOSE 通信的時間戳。
故障錄波系統（DR、DFR）
保證錄波數據中的時間標簽準確，為后續分析與調度提供依據。
控制與監控系統（SCADA）
提供高精度時間信號，使站控層系統各單元運行同步。
英文資料：
Product Name: 1MRK002305-AAr01 Time Synchronization Module
Product type: Time synchronization unit/module
Manufacturer: ABB
Applicable system: Used for ABB power automation systems, especially relay protection devices and digital substation systems (such as 670 series IEDs)
1、 Core functions
Time synchronization management
Receive external standard time signals (such as IRIG-B, SNTP/NTP, 1PPS, etc.) to provide a unified time reference for protection devices and measurement units.
High precision time distribution
Provide synchronous clock pulses to multiple system modules (such as control boards, communication boards, and recording units) to ensure accurate sequence of events (SOE).
Coordinated operation with upper level clock source
The entire station clock can be synchronized through GPS receiver, master clock device, and SCADA system.
Support multiple time protocol inputs
Usually supports IRIG-B (serial/parallel), SNTP/NTP (Ethernet), 1PPS (pulse) and other methods.
2、 Application Fields
Relay protection devices (such as REL670, REF615, RET670)
Provide a time reference for internal logical operations and event recording to ensure the accuracy of operation timing.
Digital Substation Automation System (IEC 61850 Environment)
Support station level and interval level device time synchronization, synchronizing MMS messages and GOOSE communication timestamps.
Fault recording system (DR, DFR)
Ensure the accuracy of time labels in the recorded data, providing a basis for subsequent analysis and scheduling.
Control and Monitoring System (SCADA)
Provide high-precision time signals to synchronize the operation of each unit in the station control layer system.
2.產 品 展 示
