FOXBORO SRI986-BIDS7ZZZNA閥門定位器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
FOXBORO SRI986-BIDS7ZZZNA 閥門定位器 是一款由 Foxboro（現隸屬于 Schneider Electric）生產的智能電-氣式閥門定位器，廣泛應用于過程控制系統中，用于將控制系統輸出的電信號精準地轉換為調節閥的機械動作，以實現對流體流量、壓力、溫度等變量的精準調節。
一、產品型號解析（SRI986-BIDS7ZZZNA）
該型號按 Foxboro SRI986 系列命名規則，可解讀如下（僅供參考，部分字符需廠家文檔確認）：
| 字段位 | 含義 |
|---|---|
| SRI986 | 系列名稱，智能式電-氣閥門定位器 |
| B | 輸入信號：4~20 mA 電流信號 |
| I | 執行器類型接口：線性執行器 |
| D | 顯示選項：帶數字 LCD 顯示 |
| S | 氣源接口和輸出：標準氣動輸出 |
| 7 | 防護等級/認證：本安型或防爆型（需確認） |
| ZZZNA | 特殊配置、零配件及附加選項（具體由廠商定義） |
二、核心功能
輸入信號轉換
接收控制系統的 4~20 mA 模擬電流信號；
將其轉換為對調節閥的定位動作，實現開度精確控制。
智能診斷與通訊（HART 可選）
支持 HART 通訊協議，便于遠程參數設定、狀態監測和故障診斷；
可與 DCS、AMS 系統集成，實現數字化運維。
高精度與響應性
快速響應控制信號變化，控制穩定；
零死區、低滯后，適合要求較高的閉環控制場景。
帶 LCD 顯示（D）
可直接顯示閥位、信號值、報警信息等，便于現場運維人員查看。
英文資料：
FOXBORO SRI986-BIDS7ZZZNA valve positioner is an intelligent electric pneumatic valve positioner produced by Foxboro (now part of Schneider Electric), widely used in process control systems to accurately convert electrical signals output by the control system into mechanical actions of regulating valves, in order to achieve precise adjustment of variables such as fluid flow rate, pressure, and temperature.
1、 Product Model Analysis (SRI986-BIDS7ZZZNA)
According to the naming convention of Foxboro SRI986 series, this model can be interpreted as follows (for reference only, some characters need to be confirmed in the manufacturer's documentation):
Meaning of Field Positions
SRI986 series name, intelligent electric pneumatic valve positioner
B input signal: 4-20 mA current signal
Type I actuator interface: Linear actuator
D display option: with digital LCD display
S gas source interface and output: standard pneumatic output
7 Protection level/certification: intrinsic safety or explosion-proof (to be confirmed)
ZZZNA special configurations, spare parts, and additional options (specifically defined by the manufacturer)
2、 Core functions
Input Signal Conversion
Receive 4-20 mA analog current signals from the control system;
Convert it into a positioning action for the regulating valve to achieve precise control of the opening.
Intelligent diagnosis and communication (HART optional)
Support HART communication protocol for remote parameter setting, status monitoring, and fault diagnosis;
Can be integrated with DCS and AMS systems to achieve digital operation and maintenance.
High precision and responsiveness
Quickly respond to changes in control signals and maintain stable control;
Zero dead zone and low lag, suitable for closed-loop control scenarios with high requirements.
Equipped with LCD display (D)
It can directly display valve position, signal value, alarm information, etc., making it easy for on-site operation and maintenance personnel to view.
